XTOOL D8S Bidirectional OBD2 Scanner with ECU Coding & 42+ Service Functions

Product Overview
The XTOOL D8S is a professional-grade diagnostic scanner built for repair shops, mobile mechanics, and advanced DIY users who need deeper vehicle access than a basic code reader can provide. It combines all-system diagnostics, advanced ECU coding, bidirectional control, topology mapping, and 42+ service functions in one powerful tablet-style tool. With support for modern protocols like CAN FD, DoIP, and FCA AutoAuth, plus Wi-Fi connectivity and a fast Android-based platform, it is designed for efficient troubleshooting, maintenance, and advanced diagnostic work across a wide range of vehicles.

Key Features

• Professional all-system diagnostic scanner for advanced vehicle diagnostics
• Advanced ECU coding support for compatible vehicles
• Bidirectional control for active tests and component activation
• Topology mapping for faster system-level fault detection
• OE-level all-system diagnostics
• 42+ service and maintenance functions
• Supports CAN FD and DoIP for newer vehicle communication protocols
• FCA AutoAuth support for compatible FCA vehicles
• PMI function support for compatible Ford, Mazda, and Lincoln vehicles
• VAG guided functions for supported VW and Audi group vehicles
• 8-in-1 live data graphing for clearer real-time analysis
• Wi-Fi 2.4G / 5G connectivity for flexible diagnostics and updates
• Built for workshops, technicians, and advanced DIY users
• 3 years of free software updates
• Function availability may vary by vehicle make, model, and year

Specifications

• Brand: XTOOL
• Model: D8S
• Product Type: OBD2 Diagnostic Scanner
• Display: 8-inch Capacitive Touchscreen
• Resolution: 1024 × 768
• Operating System: Android 10.0
• Processor: 4-Core 1.50GHz
• Memory: 2GB RAM + 64GB ROM
• Battery: 5000mAh / 7.3V Lithium-Polymer Battery
• Connectivity: Wi-Fi 2.4G / 5G, DB15 to VAG USB
• Supported Protocols: CAN FD, DoIP
• Main Functions: ECU Coding, Bidirectional Control, Topology Mapping, Key Programming, ECU Configuration, All-System Diagnosis, 42+ Service Functions
• Language Support: 22 Languages
• Update Policy: 3 Years Free Software Updates
• Warranty: 2 Years
• Certifications: UL, RoHS, FCC, CE
• Material: Plastic
